30W Power Amplifier

The product is applicable to L-band power amplifying, which is featured of good stability. It is able to work in the temperature range of -40 to 60. And it could be customized according to the requirement of the client.

Performance index

xmasUI-dreamdust.png Operation frequency range: 1.5GHz or 1.6GHz

xmasUI-dreamdust.png Input level: 0dBm±1dBm

xmasUI-dreamdust.png Maximum output power: ≥30W

xmasUI-dreamdust.png Gain: 45dB±2dB

xmasUI-dreamdust.png Third order intermodulation: maximum output power ≤-25dBc

xmasUI-dreamdust.png Input/output impedance: 50Ω

xmasUI-dreamdust.png Output VSWR: ≤1.5

xmasUI-dreamdust.png Power supply voltage: DC 27V

xmasUI-dreamdust.png Operation temperature range: -40~60

xmasUI-dreamdust.png Maximum power consumption: ≤500W
