The MG-762E HF vehicular log-periodical antenna is a type of tactical communication antenna that developed for fulfill the requirement of HF high-power vehicular mobile station. As the motorized device, the antenna maintains the excellent performance of log-periodical antenna and features high power capacity, strong motorized hidden capability and convenient installation, withdraw, and vehicular carrying. The antenna simplifies its own structure and strengthens the durability through “G.P” algorithm. The installation as well as withdraw of the antenna curtain could be completed manually, the measure is simple and convenient to use, which becomes the unique combat advantage.

The antenna could against the harsh electromagnetic environment effectively, and could guarantee the remote command communication. It is compliant with various types of 10kw mobile communication stations.

 Operation frequency: 4.5～26MHz

 Power capacity: 10KW

 Polarization: horizontal polarization

 Main lobe gain: 8～12dB

 VSWR: ≤2.0

 Front-to-back Ratio: 8～10dB

 RF Interface: L29-50KF

 Antenna element quantity: 21

 Height: Back main mast (vehicular lift) 15m, forward supporting mast 6m, back supporting mast 8m

 Occupied area: 35×44m

 Weight of antenna curtain and matcher: 73kg

 Weight of all supporting mast: 130kg

 Wind resistance: proper functioning at force 8 wind, not been destroyed at force 10 wind

 Deployment time: 6 people for 50 minutes
